Pulsed Travelling-wave Tube BM-1946
The following is the introduction of high quality HIGHHOPE® Pulsed Travelling-wave Tube BM-1946, hoping to help you better understand Pulsed Travelling-wave Tube BM-1946. Welcome new and old customers to continue to cooperate with us to create a better future!
Send Inquiry
Product Description
As the professional manufacture, we would like to provide you high quality HIGHHOPE® Pulsed Travelling-wave Tube BM-1946. These helix type Pulsed Traveling Wave Tubes (TWTs) provide superior wide-band and peak power performance. Our Pulsed Traveling Wave Tubes are of metal-ceramic construction for severe environmental conditions and utilize rare earth periodic permanent magnets for power-free focusing. This combination creates a rugged, light weight device suitable for any military airborne or ground-based platform.
Product Parameters
| TYPE | HF STRUCTURE | WAVEBAND | PHYSICAL DIMENSION | MAX RATING | |||
| L×W×H | OUTPUT POWER | VOLTAGE | CURRENT | FREQUENCY | |||
| (mm) | （KW） | （KV） | （A） | （GHz） | |||
| BM-1946 | RING ROD | X | 470×55×55 | 9 | 18 | 4.5 | |
Hot Tags: Pulsed Travelling-wave Tube BM-1946, High Hope, China, High Quality, Best Selling, Made in China, Manufacturers, Suppliers
